9V, 12V DC Tabletop Carbon Monoxide Detector Alarm with LCD Display

9V, 12V DC Tabletop Carbon Monoxide Detector Alarm with LCD Display

9V, 12V DC Tabletop Carbon Monoxide Detector Alarm with LCD Display
Product Details:
Contact Now
Detailed Product Description
High Light:

Mini Carbon Monoxide Detector

,

Digital Carbon Monoxide Alarm

9V, 12V DC Tabletop Carbon Monoxide Detector Alarm with LCD Display


Quick Detail:

* Battery Power+ Adapter
* High Sensitivity Sensor Nemoto brand from Japan.
* LCD Display Time, Temperature, PPM, Power,
* Low battery, Fault and End life indication
* CE, ROHS, TUV EN50291, UL2034 complication
* 5-7 years life



Description:


1. Mini Carbon Monoxide Detector Alarm with super thin design.
2. High quality Electrichemical Sensor
3. LCD Digital display with Time, Temperature, PPM, Power
4. Power Supply : Battery power + Adapter
5. Low battery , fault  and End life indication.
6. Auto Test button.
7. Multifunction for Car, Home, Hotel, School, Plane, Steamship and Portable.
8. Good quality, good reliability & high stability;
9. 85 decibel alarm sound;
10.  The sensitivity and time:
Alarm Style :Per EN50291;
      50ppm, alarm in 60-90 minutes
      100ppm, alarm in 10 ~ 40 minutes
      300ppm, alarm in 3 minutes

11. Life is 5-7 years



Applications:

Widely used in Home Kitchen, Bedroom, Study Room, Hotel, Supermarket, School, Airplane, Steamship, Car , Portable for personal or any public buildings and so on.


Specifications:

Model No.

Z-Detect

Power Supply

9V Battery + Adapter

Sensor

Electrochemical CO sensor

Alarm Standard

EN50291, UL2034

Button

Auto Test and reset button

LCD Digital Displayer

Display PPM, TIME, TEMPERATURE, POWER

Audibility

85dB ( at 1m distance )

Led Indication/Sound Pattern

Standby: Red LED light flashes once every 30 seconds
Alarm: Red Led quickly flashes 4 times with ”DI- DI- DI -DI” ,
repeat after each second.

Low-bat Indicator

Sound “DI-DI” with Red LED flash 2 times, the power symbol on
LCD screen will also keep flashing

Fault Indicator

‘Yellow LED light on and display ‘Err’ on LCD screen

Weight

140g

Power consumption

0.2mW

Sensor Life

5-7 years

Operation ambient

0°C ~ 40°C, 20% ~ 90%RH

Installation

Ceiling, Wall Mounted, Tabletop, Portable

Dimension

 Thickness: 32mm,  Width: 75mm,  Length: 125mm

Comply With

EN50291, UL2034



Competitive Advantage:

  • Power by both battery and DC Adapter.
  • Adopted highest sensitivity and steady electrochemical co sensor.
  • Three alarm standard (EN50291, UL2034, CN) available for the customers from all over the world.
